ASTM A210 Grade A1 Boiler Pipes

ASTM A210 Grade A1 Boiler Pipes

ASME SA210 Gr A1 Seamless CS Tubes

ASME SA210 Gr A1 Seamless CS Tubes

ASTM A210 Gr.A1 Tubes

ASTM A210 Gr.A1 Tubes

ASTM A210 Grade A1 Tubes & Cold Drawn bright ASME SA210 A1 Boiler Tube supplier


Check ASTM A210 Grade A1 Heat Exchanger Tubes size range

ASTM A210 Grade A1 Boiler Pipes are made for high temperature services. The ASTM A210 Grade A1 Boiler Tubes are made up of carbon steels with carbon, manganese, silicon, phosphorus and sulfur. The material can have grade A1 or grade C. The material composition changes for the different grades. The ASME SA 210 Grade A1 Steam Boiler Piping has minimum yield strength up to 275MPa and the minimum tensile strength up to 415MPa. The grade C has higher mechanical properties than the A1 grade. The ASTM A210 GR A1 Seamless Carbon Steel Tubes are made seamless hot rolled and cold drawn. The dimensions vary with the two grades. The outer diameters range from ¼ inches to 2 inches in nominal bore sizes. The wall thickness of the ASTM A210 Grade A1 Heat Exchanger Tubes range from 1mm to 8mm. The heat exchanger tubes can be made as U tubes which are special for heat exchanger applications. The SA210 Grade A1 Pressure Vessel Tubes can range up to 27000mm except for the U bend tubes. The advantage of U tubes is that they do not need bend fittings to bend the pipes. The pipes can have plain, beveled and coupling pipe end types. The ASTM A210 Gr.A1 Tubes can be rolled, cold drawn or normalizing rolled. The pipes can also be epoxy resin coated, 3LPE coated or color paint coated. The ASTM A210 Grade 1 Pipe can be tested with H2 service, IBR, PWHT and other tests to adhere to the standard specifications.

Specification Table of ASTM A210 Grade A1 Boiler Pipes
Specification Of ASTM A210 / ASME SA210 GR A1 Tubes
Standard A210 Grade A1 Tubes, SA210 Grade A1 Tubes, A210 Grade A Tubes, SA210 Grade A Tubes, SA210 Grade B Tubes, A210 Grade B Tubes, A210 Grade C Tubes, SA210 Grade C Tubes.
Type SA210 & A210 Seamless Tubes.
Length Double Random & Required Length, Single Random, & Custom Size Available.
Shape/Form Round Tubes, Coiled Tubes, “U” Shape Tubes.
Pipes & Tubes End Plain End, Beveled End, Treaded Protected With Plastic Caps.
Application ASTM A210 Gr A1 & ASME SA210 Gr A1 Tubes Are Used For Low, Middle & High pressure boiler / pressure purpose.
Most frequent types of ASTM A210 Grade A1 Boiler Tubes
Astm A210/asme Sa210 Grade A1 Carbon Steel Seamless Pipe

Astm A210/asme Sa210 Grade A1 Carbon Steel Seamless Pipe

Astm A210 Grade A1 Pipe Tubes

Astm A210 Grade A1 Pipe Tubes

Astm A210 Asme Sa210 A1 Or Grade C Cold Drawn Seamless Carbon Steel Boiler Tube

Astm A210 Asme Sa210 A1 Or Grade C Cold Drawn Seamless Carbon Steel Boiler Tube

Seamless Tube Astm A210 Grade A1

Seamless Tube Astm A210 Grade A1

Low Temp Alloy Steel Tube Sa210 A1

Low Temp Alloy Steel Tube Sa210 A1

Sa210 A1 Seamless Boiler Tube

Sa210 A1 Seamless Boiler Tube

Astm A210 A1 Welded Steel Pipe

Astm A210 A1 Welded Steel Pipe

Sa210 A1 Heat Exchanger Tube

Sa210 A1 Heat Exchanger Tube

ISO certified ASME SA210 Gr A1 Tube supplier in India. View SA210 A1 Boiler Tube Sizes and Chemical Properties

ASTM A210 Gr A1 Chemical Composition
Element Carbon Manganese Phosphorus Sulfur
Grade C 0.35 0.29-1.06 0.035 0.035
grade A1 0.27 0.93 0.035 0.04
Sa 210 Gr A1 Properties
Grade
Tensile Strength(Mpa)
Yield Strength(Mpa)
Elongation(%)
A1
≥415
≥255
≥30
ASME SA 210 Grade A1 Steam Boiler Piping Tolerance Chart
Seamless, Cold-Finished Tubes

Outside Diameter

In. (mm)

Wall thickness Tolerance %
Over (+) Under (-)
1 ½ (38.1) and under 20 0
Over 1½ (38.1) 22 0
Check dimensions and specification of Carbon Steel GR.A1 ASME SA210 Hot-finished Seamless Tubes
ASTM A210 Dimensional Tolerance
Cold-Finished Seamless Tubes

Outside Diameter

In. (mm)

Permissible Variations In. (mm)
Over (+) Under (-)
Under 1 (25.4) 0.004 (0.10) 0.004 (0.10)
1 to 1 ½ (25.4 to 38.1), Incl 0.006 (0.15) 0.006 (0.15)
Over 11⁄2 to 2 (38.1 to 50.8), Excl 0.008 (0.20) 0.008 (0.20)
2 to 21⁄2 (50.8 to 63.5), Excl 0.010 (0.25) 0.010 (0.25)
21⁄2 to 3 (63.5 to 76.2), Excl 0.012 (0.30) 0.012 (0.30)
ASTM A210 GR A1 Seamless Carbon Steel Tubes Length Tolerance Chart
Cold-Finished Seamless Tubes
Outside Diameter,
In.(mm)
Cut Length, in.(mm)
Over (+) Under (-)
All Sizes 3⁄16 [5] 0 [0]
Under 2 (50.8) 1⁄8 [3] 0 [0]
2 (50.8) and over 3⁄16 [5] 0 [0]
Under 2 (50.8) 1⁄8 [3] 0 [0]
2 (50.8) and over 3⁄16 [5] 0 [0]
These permissible variations in length apply to tubes before bending. They apply to cut lengths up to and including 24 ft [7.3 m]. For lengths greater than 24 ft [7.3 m], the above over-tolerances shall be increased by 1⁄8 in. [3 mm] for each 10 ft [3 m] or fraction thereof over 24 ft or 1⁄2 in. [13 mm], whichever is the lesser.
Test Pressure Rating of ASTM A210 Grade A1 Heat Exchanger Tubes

Each tube shall be subjected to the hydrostatic pressure test, or instead of this test, a nondestructive test may be used when specified by the purchaser.

Hydrostatic Test Pressures
Outside Diameter of Tube, in. [mm] Hydrostatic Test Pressure, psi [MPa]
Under 1 [25.4] 1000 [7]
1 to 11⁄2 [25.4 to 38.1], excl 1500 [10]
11⁄2 to 2 [38.1 to 50.8], excl 2000 [14]
2 to 3 [50.8 to 76.2], excl 2500 [17]
Tubo astm a210 Uses
  • Petrochemical Industry
  • Chemical Industry
  • Oil and Gas Industry
  • Pulp & Paper Indusry
  • Power Plant Industry
  • Food Processing Industry
  • Pharmaceuticals Industry
  • Energy Industry
  • Aerospace Industry
SA210 Grade A1 Pressure Vessel Tubes Standard Chart
GERMANY

DIN 17175 St 35.8, DIN 17175 St45.8, DIN 17175
17 Mn 4, DIN 17175 19 Mn 5, DIN 17175 15 Mo 3, DIN 17175 13 CrMo 44, DIN 17175 10 CrMo 910, DIN 17175 14 MoV63, DIN 17175 X20CrMoV12 1.

UK
  • BS 3602 Pt.1 Gr. 360, BS 3059 Pt.2 Gr. 360,
  • BS 3602 Pt.1 Gr. 430, BS 3059 Pt.1 Gr. 440,
  • BS 3602 Pt.1 Gr. 460, BS 3059 Pt.1 Gr. 440,
  • BS 3059 Pt.2 Gr. 243, BS 3604 Gr. 620,
  • BS 3059 Pt.2 Gr. 620, BS 3604 Gr. 622,
  • BS 3059 Pt.2 Gr. 622, BS 3059 Pt.2 Gr. 762.
USA
  • ASTM A160 Gr. A, ASTM A179 Gr. A,
  • ASTM A192 Gr. A, ASTM A53 Gr. A,
  • ASTM A106 Gr. B, ASTM A210 Gr. A1,
  • ASTM A106 Gr. C, ASTM A210 Gr. C,
  • ASTM A213 Gr. T11, ASTM A335 Gr. P11,
  • ASTM A335 Gr. P22.
Manufacturer of ASME SA210 Grade A1 Pressure Vessel Tubes, Refer ASTM A210 Grade 1 Pipe Wall Thickness
Wall Thickness of ASTM A210 Gr.A1 Tubes
SA210 Pipe Types Out diameter Wall thickness Length
SA210 tube material (Custom Sizes) 1/2" NB - 60" NB As per requirement Custom
SA210 gr a1 tube (in Stock + Custom Sizes) 1/2" NB - 24" NB As per requirement Custom
SA210 ERW Tube (Custom Sizes) 1/2" NB - 24" NB As per requirement Custom
Pressure Rating Chart of ASTM A210 Grade 1 Pipe
Maximum Allowable Pressure (psi)
NPS Outside Diameter Schedule
(in) (in) 10 20 30 STD 40 60 XS 80 100 120 140 160 XXS
1/4 0.54 7985 7985 10798 10798
3/8 0.675 6606 6606 9147 9147
1/2 0.84 6358 6358 8575 8575 10908 17150
3/4 1.05 5273 5273 7187 7187 10220 14373
1 1.315 4956 4956 6670 6670 9316 13340
1 1/4 1.66 4133 4133 5638 5638 7380 11276
1 1/2 1.9 3739 3739 5158 5158 7247 10316
2 2.375 3177 3177 4498 4498 7097 8995
2 1/2 2.875 3460 3460 4704 4704 6391 9408
3 3.5 3024 3024 4200 4200 6132 8400
3 1/2 4 2769 2769 3896 3896
4 4.5 2581 2581 3670 3670 4769 5782 7339
5 5.563 2273 2273 3303 3303 4404 5505 6606
6 6.625 2071 2071 3195 3195 4157 5318 6390
8 8.625 1420 1574 1829 1829 2307 2841 2841 3375 4085 4613 5147 4971
10 10.75 1140 1399 1664 1664 2279 2279 2708 3277 3847 4558 5128 4558
12 12.75 961 1268 1441 1560 2160 1922 2644 3244 3843 4324 5042 3843
14 14 875 1092 1313 1313 1533 2079 1750 2625 3283 3829 4375 4921
16 16 766 956 1148 1148 1531 2009 1531 2585 3157 3733 4404 4882
18 18 681 849 1192 1021 1530 2042 1361 2553 3147 3743 4252 4848
20 20 613 919 1225 919 1455 1989 1225 2526 3138 3675 4288 4824
22 22 557 835 1114 835 1949 1114 2506 3063 3619 4176 4733
24 24 510 766 1147 766 1405 1978 1021 2489 3126 3700 4210 4786
30 30 510 817 1021 613 817
32 32 478 766 957 574 1054
34 34 450 721 901 540 992
36 36 425 681 851 510 1021
42 42 583 729 438 875
Tubo astm a210 a1 Sizes
Size NPS Pipe O.D. Wall Thickness Pipe I.D. Weight per Foot Standard to XXHY Schedule
Pipe #
Section Modulus Gallon Capacity Per Linear Foot
1/2 0.84 0.109 0.622 0.85 STD 40 .0407 .0158
0.147 0.546 1.09 XHY 80 .0478 .0122
0.188 0.464 1.31 160 .0528 .0088
0.294 0.252 1.72 XXHY .0577 .0026
3/4 1.05 0.113 0.824 1.13 STD 40 .0705 .0277
0.154 0.742 1.48 XHY 80 .0853 .0225
0.219 0.612 1.95 160 .1006 .0153
0.308 0.434 2.44 XXHY .1103 .0077
1 1.315 0.133 1.049 1.68 STD 40 .1328 .0449
0.179 0.957 2.17 XHY 80 .1606 .0374
0.250 0.815 2.85 160 .1904 .0271
0.358 0.599 3.66 XXHY .2136 .0146
1 1/4 1.66 0.140 1.380 2.27 STD 40 .2346 .0777
0.191 1.278 3.00 XHY 80 .2913 .0666
0.250 1.160 3.77 160 .3421 .0549
0.382 0.896 5.22 .4110 .0328
1 1/2 1.90 0.145 1.610 2.72 STD 40 .3262 .1058
0.200 1.500 3.63 XHY 80 .4118 .0918
0.281 1.338 4.86 160 .5079 .0730
0.400 1.100 6.41 .5977 .0494
2 2.375 0.109 2.157 2.64 10 .4205 .1898
0.154 2.067 3.66 STD 40 .5606 .1743
0.218 1.939 5.03 XHY 80 .7309 .1534
0.250 1.875 5.68 .8045 .1434
0.281 1.813 6.29 .8666 .1344
0.344 1.687 7.47 160 .9806 .1161
0.436 1.503 9.04 XXHY 1.1043 .0922
2 1/2 2.875 0.120 2.635 3.53 10 .6870 .2833
0.203 2.469 5.80 STD. 40 1.0640 .2487
0.216 2.443 6.14 1.1169 .2435
0.250 2.375 7.02 1.2468 .2301
0.276 2.323 7.67 XHY 80 1.3386 .2202
0.375 2.125 10.02 160 1.6371 .1842
0.552 1.771 13.71 XXXHY 1.9971 .1280
3 3.50 0.120 3.260 4.34 1.0411 .4336
0.156 3.188 5.58 1.3122 .4147
0.172 3.156 6.12 1.4265 .4064
0.188 3.124 6.66 1.5342 .3984
0.216 3.068 7.58 STD. 40 1.7241 .3840
0.250 3.000 8.69 1.9372 .3672
0.281 2.938 9.67 2.1207 .3521
0.300 2.900 10.26 XHY 80 2.2253 .3431
0.438 2.624 14.34 160 2.8774 .2811
0.600 2.300 18.6 XXHY 3.4243 .2158
3 1/2 4.0 0.120 3.760 4.98 10 1.3776 .5768
0.226 3.548 9.12 STD. 140 2.3939 .5136
0.250 3.500 10.02 2.6001 .4998
0.281 3.438 11.17 2.8562 .4821
0.318 3.364 12.52 XHY 80 3.1400 .4617
0.636 2..728 22.87 XXHY 4.8795 .3085
4 4.5 0.120 4.260 5.62 10 1.7612 .7404
0.156 4.188 7.24 2.2354 .7156
0.188 4.124 8.67 2.6296 .6942
0.203 4.094 9.32 2.8173 .6838
0.219 4.062 10.02 3.0184 .6725
0.237 4.026 10.80 STD. 40 3.2145 .6613
0.250 4.000 11.36 3.3611 .6528
0.281 3.938 12.67 60 3.7021 .6326
0.312 3.876 13.97 4.0273 .6126
0.337 3.826 15.00 XHY 80 4.2713 .5972
0.438 3.624 19.02 120 5.1790 .5361
0.531 3.438 22.53 160 5.8997 .4822
0.674 3.152 27.57 XXHY 6.7927 .4054
5 5.563 0.188 5.187 10.80 4.1161 1.0979
0.219 5.125 12.51 4.7279 1.0716
0.258 5.047 14.63 STD. 40 5.4500 1.0391
0.281 5.001 15.87 5.8644 1.0204
0.312 4.939 17.51 6.4074 .99647
0.344 4.875 19.19 6.9358 .9696
0.375 4.813 20.80 XHY 80 7.4300 .9449
0.500 4.563 27.06 120 9.2534 .8495
0.625 4.313 32.99 160 10.7976 .7590
0.750 4.063 38.59 XXHY 12.0954 .6734
6 6.625 0.109 6.407 7.59 5 3.5769 1.6748
0.134 6.357 9.30 10 4.3475 1.6488
0.156 6.313 10.79 5.0107 1.6260
0.188 6.249 12.94 5.9351 1.5937
0.203 6.219 13.94 6.3804 1.5780
0.219 6.187 15.00 6.8261 1.5620
0.250 6.125 17.04 7.6905 1.5306
0.280 6.065 18.99 STD. 40 8.4958 1.5008
0.312 6.001 21.06 9.3416 1.4688
0.344 5.937 23.10 10.111 1.4391
0.375 5.875 25.05 10.893 1.4082
0.432 5.761 28.60 XHY 80 12.224 1.3541
0.500 5.625 32.74 13.711 1.2909
0.562 5.501 36.43 120 14.9806 1.2346
0.625 5.375 40.09 16.1821 1.1787
0.719 5.187 45.39 160 17.8243 1.0977
0.864 4.897 53.21 XXHY 20.025 .9784
1.000 4.625 60.13 21.7719 .8727
1.125 4.375 66.14 23.1237 .7809
ASTM A210 Gr A1 pipe Weight Chart
Sch 5 Sch 10 Sch 40 Sch 80 Sch 160
1/2
3/4
1
1.25
1.5
2
2.5
3
3.5
4
5
6
8
10
12
14
16
18
20
22
24
